Supports PV inverter, generators, and microgrid inputs, suitable for new and modified photovoltaic and microgrld systems
Supports multiple inverters with EPS output in pamallel, and can be expanded to small industrial and commercial applications
Support RSD and AFCI optional configurations to provide system protection
Mains and PV input power owersized at a ratio of 1.5, resulting in a more stable system operation
App real-time monitoring, supports online remote OTA upgrades, easy operation and maintenance
Specification
PV Input Power
18kW
Battery Type
Li-ion, Lead-acid battery
Input Voltage Range
184~276VAC
Rated Output Current
45.5A/43.5A; 54.5A/52.2A
Surge Protection
DC Type II/AC Type III
Dimensions(WxHxD)(mm)
450 x 600 x 270
PV Input Voltage Range
100VDC - 550VDC
Max. Charge/Discharge Current
180A/180A; 250A/250A
Rated Output Voltage
1/N/PE.220VAC/230VAC
Weight
45kg
Protection
Over/under voltage, over/under-frequency, over load, output short-circuit, over temperature, residual current monitoring unit, output over-current, insulation resistance detection, anti islanding, surge protection
