Highly quality LFP cell testified DOD circle >6000
Perfluoro firefighting & Non EV ( vented explosion ) construction design prevent thermal runaway and fire event
Efficient and Flexible
All-in-one system 400VAC I/O, plug-in-play, liquid cooling system reduce 40% space occupation
On-grid & black start working model
HF power modular PCS base on three-level interter topology, >90% AC efficiency
Black start allow system to backup when utility goes off, max 10 units parallel
Smart and Robust
Cloud monitoring system, remote monitoring and OTA
IP54 with C4 protection and build-in PTC heater on celll evel, against extremely condition
Low OPEX
AI enchant two level BMS accuracy control battery state, saving maintenance cost
Liquid cooling BC management System, keep temperature consistency between battery pack <3%, reduce 30% power consumption, extend battery life circle more than 2 years
Specification
Total Battery Capacity
261kWh
Rated Frequency
50/60Hz (± 2.5Hz)
Cooling Method
Liquid cooling
Protection
Reverse Connection Protection; DC Switch; Over - Temp Protection; Insulation Monitoring (Bat Side); DC/AC Surge Protection
