IP66 all-aluminum chassis, adaptable to outdoor environment
APP real time monitoring, easy maintenance
High charge/discharge efficiency, compatible with lithium batteryand lead-acid battery
Outstanding off-grid output performance, adaptable to various non-linear load
Flexibly settable charge/discharge time section and power, peak load shaving
Specification
PV Input Power
4680W; 6500W; 7800W
Battery Type
Li-ion, Lead-acid battery
Max. Discharge Current
66A; 75A; 100A; 120A
Max. Output Current
13.6A; 16.4A; 22.7A; 27.3A
Rated Output Voltage
230VAC (208/220/240VAC settable)
Protection
Over/under voltage, over/under-frequency, over load, output short-circuit, over temperature, residual current monitoring unit, output over-current, insulation resistance, anti islanding, surge protection
